Loader 90ziv-2
Technical Specifications
|
Engine Specifications |
Model |
NISSAN PE6T |
|
Type |
4 cycle diesel with turbocharged and direct fuel injection |
|
Cylinder |
6 |
|
Engine rated power |
203kw/272hp |
|
Capacity(lit) |
11.67 |
|
Specifications,
Weight
Dimensions
Working Speed |
Operating weight(kg) |
21100 |
|
Bucket capacity ,SAE |
3.2-4.2 |
|
Tire size |
26.5-25-20,L3 |
|
Overall height(mm) |
3475 |
|
Overall length with bucket (mm) |
8540 |
|
Overall width without bucket (mm) |
2845 |
|
Max loading height (mm) |
5730 |
|
Max dumping height |
2840 |
|
Max break tilt angle(degree) |
40 |
|
Bucket raise time (second) |
6.1 |
|
bucket lower time (second) |
3.0 |
|
Bucket dumping time (second) |
1.6 |
|
Travel Speed
(km/h) |
|
Back |
Front |
|
Gear 1st |
8 |
7.7 |
|
Gear 2nd |
13. 3 |
12.9 |
|
Gear 3rd |
22.1 |
21.6 |
|
Gear 4th |
34.6 |
34.0 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
