Engine specifications

Model

CUMMINS / QSB 6.7

Type

4 cycle diesel with turbocharged and direct fuel injection

cylinder

6

Engine rated power

160kw/215ph

Capacity(lit)

7. 6

Specifications,

Weight ,

Dimension,

Working speed

Operating weight (kg)

17900

Bucket capacity ,SAE

3.1 – 2.7

Tire size

23.5-25, 20PR, L3

Overall height (mm)

3440

Overall length with bucket

8060

Overall width without bucket (mm)

2900

Max loading height (mm)

5540

Max dumping height

3000

Max breaker tilt angle(degree)

40

Bucket raise time (second)

6.2

Bucket lower time (second)

3

Bucket dumping time (second)

1.3

Travel speed

(km/h)

Back

Front

Gear 1^st

6.6

6.2

Gear 2^nd

12.3

11.7

Gear 3^rd

23.3

22.3

Gear 4^th

***

34.3
